| MODEL | DL-120 | DL-145 |
|---|---|---|
| Maximum Pallet Size | 80 cm x 120 cm ( 31 1/2 in x 47 1/4 inch ) |
105 cm x 145 cm ( 41 5/16 in x 57 1/16 inch ) |
| Maximum Place Size | 84 cm x 127 cm ( 33 1/16 in x 50 inch ) |
109 cm x 152 cm ( 42 15/16 in x 59 7/8 inch ) |
| Maximum Stack Height | 91 cm ( 36 inch ) | 91 cm ( 36 inch ) |
| Maximum Lifting Weight | 133 cm x 144 cm ( 52 3/8 in x 56 7/8 inch ) |
158 cm x 169 cm ( 62 1/4 in x 66 1/2 inch ) |
| Reguired Space(dxw)cm/inch | 148 cm (58 1/4 inch ) | 148 cm (58 1/4 inch ) |
| Machine Height | 140 cm | 180 cm |
| Maximum horsepower KW | 1.0 | 1.5 |
| Total weight kg | 700 | 750 |
※ Specifi cation could be changed for improvement without prior notice.
